Scenario.TPV29.TPV29 Class Reference

Part of a series of benchmarks by the Statewide California Earthquake Center (SCEC) More...

Inheritance diagram for Scenario.TPV29.TPV29:

Collaboration diagram for Scenario.TPV29.TPV29:

Public Member Functions
	initial_conditions (self)
	generate_required_files (self, order)
Public Member Functions inherited from Scenario.Scenario.Scenario
	generate_file_from_template (self, template_file, full_qualified_filename, dictionary)
	copy_file_to_current_folder (self, current_filename, full_qualified_filename)

Static Public Attributes
list	domain_offset = [-3.4, 0.0, -3.4]
list	domain_size = [48.6, 48.6, 48.6]
float	end_time = 20.0
list	tracer_coordinates
list	fault_coordinates
Static Public Attributes inherited from Scenario.Scenario.Scenario
list	domain_offset = [1., 1., 1.]
list	domain_size = [1., 1., 1.]
float	end_time = 0.0
list	tracer_coordinates = []

Detailed Description

Part of a series of benchmarks by the Statewide California Earthquake Center (SCEC)

Single rough planar vertical strike-slip fault in a linear elastic medium.

The description of the scenario can be found at: https://strike.scec.org/cvws/tpv29_30docs.html

Definition at line 7 of file TPV29.py.

Member Function Documentation

generate_required_files()

Scenario.TPV29.TPV29.generate_required_files	(		self,
			order )

Reimplemented from Scenario.Scenario.Scenario.

Definition at line 99 of file TPV29.py.

References Scenario.Scenario.Scenario.copy_file_to_current_folder(), and Scenario.Scenario.Scenario.generate_file_from_template().

Here is the call graph for this function:

initial_conditions()

Scenario.TPV29.TPV29.initial_conditions

(

self

)

Reimplemented from Scenario.Scenario.Scenario.

Definition at line 92 of file TPV29.py.

Field Documentation

domain_offset

list Scenario.TPV29.TPV29.domain_offset = [-3.4, 0.0, -3.4]

static

Definition at line 16 of file TPV29.py.

domain_size

list Scenario.TPV29.TPV29.domain_size = [48.6, 48.6, 48.6]

static

Definition at line 17 of file TPV29.py.

end_time

float Scenario.TPV29.TPV29.end_time = 20.0

static

Definition at line 19 of file TPV29.py.

fault_coordinates

list Scenario.TPV29.TPV29.fault_coordinates

static

Initial value:

=  [
          # on-fault at surface (3)
          [20.0, 0.0, 15.0], #surface above fault hypocenter
          [20.0, 0.0, 25.0],
          [20.0, 0.0, 35.0],
          #on-fault, general (21)
          [20.0, 15.6,  2.0],
          [20.0,  5.0,  5.0],
          [20.0, 12.0,  5.0],
          [20.0,  1.4,  9.0],
          [20.0, 10.1, 11.1],
          [20.0, 10.0, 15.0], #on fault hypocenter
          [20.0, 16.0, 15.0],
          [20.0,  6.1, 15.8],
          [20.0, 12.0, 20.0],
          [20.0,  6.2, 14.3],
          [20.0,  6.0, 14.6],
          [20.0, 12.0, 25.0],
          [20.0,  5.7, 25.1],
          [20.0,  4.7, 25.9],
          [20.0, 15.3, 29.0],
          [20.0, 15.3, 29.3],
          [20.0,  5.0, 30.0],
          [20.0, 11.0, 30.0],
          [20.0, 13.0, 35.0],
          [20.0, 10.5, 36.7],
          [20.0,  4.5, 37.0]
    ]

Definition at line 63 of file TPV29.py.

tracer_coordinates

list Scenario.TPV29.TPV29.tracer_coordinates

static

Definition at line 21 of file TPV29.py.

---

The documentation for this class was generated from the following file:

• applications/exaseis/ExaSeis_core/Scenario/TPV29.py
